Description
SRV3KI
Overview
| Lead time |
Usually in Stock
|
|---|
| rated power in W |
2400 W
|
|
|---|---|---|
| rated power in VA |
3000 VA
|
|
| nb of power socket outlets |
4 India 2/3-pin 6A
|
|
| output connector type |
Hard wire 3-wire (H N + E) 1
|
|
| Main Output Voltage |
230 V
|
|
| Other Output Voltage |
220 V
240 V |
|
| plug standard |
IEC 60320 C20
|
|
| number of rack unit |
2U
|
|
| cable length |
1.5 m
|
|
| number of cables |
1
|
| max runtime |
3 min
|
|
|---|---|---|
| Number of power module filled slots |
0
|
|
| Number of power module free slots |
0
|
|
| redundant |
No
|
|
| provided equipment |
Basic UPS signalling RS-232 cable
CD with software Country-specific detachable power cord Rack mounting brackets Stabilization/wall mounting feet User manual USB cable |
| mounting mode |
Rack-mounted
|
|
|---|---|---|
| height |
8.8 cm
|
|
| width |
43.8 cm
|
|
| depth |
63.2 cm
|
|
| net weight |
28 kg
|
|
| colour |
Black
|
| Main Input Voltage |
230 V AC
|
|
|---|---|---|
| input protection type |
Circuit breaker
|
|
| switching current capacity |
20 A
|
|
| Other Input Voltage |
220 V
240 V |
|
| input voltage limits |
110…280 V half load
160…280 V full load |
|
| network frequency |
40…70 Hz auto sensing
|
| Maximum configurable power in VA |
3000 VA
|
|
|---|---|---|
| Maximum configurable power in W |
2400 W
|
|
| output frequency |
50/60 Hz +/- 3 Hz sync to mains
|
|
| harmonic distortion |
3 %
|
|
| UPS type |
Double conversion online
|
|
| Wave type |
Sine wave
|
|
| efficiency |
90 % (full load)
|
|
| additional information |
Configurable for 220 : 230 or 240 nominal output voltage
|
|
| bypass type |
Internal bypass (automatic and manual)
|
|
| crest factor |
3 : 1
|
| product certifications |
BIS
|
|---|
| acoustic level |
50 dBA
|
|
|---|---|---|
| heat dissipation |
910 Btu/h
|
|
| operating altitude |
0…3000 m
|
|
| ambient air temperature for operation |
0…40 °C
|
|
| ambient air temperature for storage |
-20…60 °C
|
|
| storage altitude |
0…15000 m
|
|
| IP degree of protection |
IP20
|
|
| relative humidity |
0…95 % non-condensing
|
|
| storage Relative Humidity |
Non-condensing 0…95 %
|
| battery type |
Lead-acid battery
|
|
|---|---|---|
| battery voltage |
72 V
|
|
| number of battery filled slots |
1
|
|
| number of battery free slots |
0
|
|
| Battery recharge time |
4 h
|
|
| battery charger power |
60 W rated
|
| alarm |
Audible and visible alarms prioritized by severity
|
|
|---|---|---|
| control panel |
Multifunction LCD status and control console
|
| Surge energy rate |
600 J
|
|---|
| Package 1 Weight |
32 kg
|
|
|---|---|---|
| Package 1 Height |
22.8 cm
|
|
| Package 1 width |
57 cm
|
|
| Package 1 Length |
79.4 cm
|
| REACh Regulation | ||
|---|---|---|
| EU RoHS Directive |
Under investigation
|
| Warranty |
2 years repair or replace
|
|---|
