Introduction
The Tenda TEG1024D is an unmanaged 24-port RJ45 Gigabit Ethernet switch designed to deliver high performance with a switching capacity of 48Gbps and a forwarding rate of 35.7 Mpps. Its robust metal housing and 6KV lightning protection make it ideal for small to medium-sized businesses, data centers, and surveillance systems.
Key Applications
- Expanding networks in small and medium-sized offices.
- High-definition video surveillance systems.
- Work environments requiring high-speed data transfer.
Usage Warnings
- Avoid exposing the device to moisture or wet environments.
- Use CAT5e or better network cables to ensure optimal performance.
- Ensure proper ventilation around the device to prevent overheating.
Technical Specifications
| Specification | Value |
|---|---|
| Number of Ports | 24 RJ45 10/100/1000 Mbps (Auto MDI/MDIX) |
| Switching Capacity | 48 Gbps |
| Forwarding Rate | 35.7 Mpps |
| MAC Address Table | 8K |
| Switching Mode | Store-and-Forward |
| Lightning Protection | 6KV for ports and power supply |
| Maximum Power Consumption | 12W |
| Dimensions | 294 × 178 × 44 mm |
| Operating Temperature | 0°C to 45°C |
| Storage Temperature | -40°C to 70°C |
| Operating Humidity | 10% to 90% RH (non-condensing) |
| Storage Humidity | 5% to 90% RH (non-condensing) |
| Certifications | CE, FCC, RoHS |
