Tenda TEF1109P-8-102W 9-Port Unmanaged PoE Switch
The Tenda TEF1109P-8-102W is a 9-port 10/100Mbps unmanaged switch featuring 8 PoE ports compliant with IEEE802.3af/at standards, delivering a total PoE power budget of up to 92W. Its fanless design ensures silent operation, and 6KV lightning protection safeguards against electrical surges, making it ideal for video surveillance and wireless networking in small to medium-sized businesses.
Key Applications
- Powering IP surveillance cameras without separate power sources.
- Supporting wireless access points (APs) for network expansion.
- Providing reliable networking solutions for offices, hotels, and educational institutions.
Usage Warnings
- Ensure the total PoE load does not exceed 92W to prevent malfunctions.
- Use CAT5e or higher-grade cables for optimal performance.
- Avoid installing the device in damp or dusty environments.
Technical Specifications
| Specification | Value |
|---|---|
| Number of Ports | 9 RJ45 (8 PoE + 1 uplink) |
| Port Speed | 10/100 Mbps |
| Network Standards | IEEE 802.3, 802.3u, 802.3x, 802.3af/at |
| Switching Capacity | 1.8 Gbps |
| Packet Forwarding Rate | 1.34 Mpps |
| MAC Address Table | 2000 entries |
| Total PoE Power Budget | 92W |
| Max PoE per Port | 30W |
| Operating Modes | Standard / VLAN |
| Lightning Protection | 6KV |
| Dimensions | 177.5 × 104 × 26 mm |
| Operating Temperature | 0~45°C |
