The Netsys NS-404OM4012 is a high-performance, 12-core OM4 multi-mode fiber optic cable designed to meet the demands of modern, high-bandwidth data environments. Whether you’re scaling a data center or backbone infrastructure, this cable is built for 40G and 100G Ethernet applications.
Key Specifications
| Feature | Detail |
| Model Number | NS-404OM4012 |
| Fiber Count | 12 Cores |
| Fiber Type | Multi-Mode OM4 |
| Core/Cladding Diameter | 50/125µm |
| Bandwidth (EMB) | 4700 MHz·km @ 850nm |
| Jacket Material | LSZH (Low Smoke Zero Halogen) or PVC (Depending on variant) |
Core Benefits
-
Future-Proof Performance: Optimized for laser-based equipment (VCSEL), the OM4 fiber supports 10Gbps up to 550 meters and 40/100Gbps up to 150 meters, providing a significant edge over standard OM3 cables.
-
High Density: With 12 individual fiber cores bundled into a single jacket, it maximizes space in conduits and patch panels, making it ideal for high-density networking racks.
-
Low Signal Loss: The 50/125 micron construction ensures minimal attenuation and high-speed data integrity over medium distances.
-
Versatile Application: Excellent for backbone cabling, horizontal distribution, and interconnecting high-speed switches in enterprise-level LANs.
Technical Overview
The NS-404OM4012 is “Laser Optimized,” meaning it is specifically designed to eliminate Differential Mode Delay (DMD), which can occur when using high-speed laser light sources. This ensures that your data arrives intact and at the highest possible speeds.
