The Netsys NS-403OM3008 is a high-performance 8-core OM3 Multimode fiber optic cable, specifically engineered to meet the demands of modern 10 Gigabit Ethernet (10GbE) networks. Utilizing Laser-Optimized Multimode Fiber (LOMMF) technology, this cable provides a reliable, high-bandwidth foundation for short-to-medium distance data transmission in enterprise and data center environments.
Technical Specifications: NS-403OM3008
| Feature | Details |
| Brand/Model | Netsys NS-403OM3008 |
| Fiber Category | OM3 Multimode (Laser Optimized) |
| Fiber Count | 8 Cores |
| Core/Cladding | 50/125µm |
| Effective Modal Bandwidth | 2000 MHz·km @ 850nm |
| 10G Ethernet Support | Up to 300 Meters |
| 40G/100G Support | Up to 100 Meters |
| Attenuation | $\leq 3.0$ dB/km @ 850nm; $\leq 1.0$ dB/km @ 1300nm |
Key Product Features
-
Optimized for VCSELs: Designed for use with 850nm Vertical-Cavity Surface-Emitting Lasers, ensuring high-speed data integrity over 10Gbps links.
-
8-Core Efficiency: The 8-strand configuration is perfectly suited for 40G (4x10G) parallel optics applications or providing redundant links for critical network hardware.
-
Cost-Effective Scalability: Offers a significant performance boost over OM1/OM2 legacy fiber while remaining more budget-friendly than OM4 for runs under 300 meters.
-
Industry Standard Jacket: Features the standard Aqua-colored jacket for easy identification within high-density cable trays and racks.
Common Applications
-
Intra-Building Backbones: Reliable connection between server rooms and telecommunications closets.
-
Data Center Interconnects: High-speed patching between switches, storage arrays, and high-performance servers.
-
Video & Multimedia: Low-latency transmission for high-definition video distribution and professional AV setups.
-
Fiber-to-the-Zone (FTTZ): Extending high-speed fiber connectivity closer to the end-user or workgroups.
