Product Overview: NS-404OM4008
The NS-404OM4008 is a premium 8-core OM4 Multimode fiber optic cable engineered for high-speed networking. Optimized for 850nm Laser-Optimized Multimode Fiber (LOMMF) applications, this cable is the ideal backbone for 10G, 40G, and 100G Ethernet deployments where reliability and low attenuation are critical.
Key Technical Specifications
| Feature | Details |
| Fiber Type | Multimode OM4 (Laser Optimized) |
| Core/Cladding Diameter | 50/125µm |
| Fiber Count | 8 Cores |
| Bandwidth | 4700 MHz·km (Effective Modal Bandwidth @ 850nm) |
| Data Rate Support | 10Gbps up to 550m; 40/100Gbps up to 150m |
| Wavelength | 850nm / 1300nm |
| Color Code | Usually Aqua (Standard for OM4) |
Main Features
-
High Bandwidth: Specifically designed to handle the demands of modern data centers, providing significantly more headroom than OM3.
-
Future-Proofing: Supports migration paths from 10G to 40G and 100G Ethernet architectures.
-
Robust 8-Core Construction: Allows for multiple high-speed links or redundancy in a single cable pull, saving space in conduits and racks.
-
Low Signal Loss: Tight manufacturing tolerances ensure minimal attenuation and macro-bending sensitivity.
Common Applications
-
Data Centers: High-density patching and backbone cabling.
-
Enterprise Networks: Connecting switches and servers across floors or buildings.
-
Storage Area Networks (SAN): High-speed data retrieval and storage links.
-
Horizontal Cabling: Supporting high-end workstations and multimedia distribution.
