Introduction
The Grandstream GWN7803P is an ideal solution for small to medium-sized businesses aiming to build robust, secure, and manageable networks. This switch offers 24 Gigabit PoE/PoE+ ports with a total power budget of 360W, enabling the connection and powering of various devices such as IP phones, wireless access points, and surveillance cameras.
Key Applications
- Powering and connecting VoIP phones and wireless access points.
- Network management in offices, hotels, schools, and residential complexes.
- Supporting applications requiring high-speed data transfer and advanced security.
Usage Warnings
- Avoid operating the device outside the recommended temperature range (0°C to 45°C).
- Ensure proper ventilation to prevent overheating.
- Do not open or modify the device to avoid voiding the warranty.
Technical Specifications
| Specification | Details |
|---|---|
| Ports | 24 Gigabit PoE/PoE+ ports, 4 Gigabit SFP ports |
| Total PoE Power Budget | 360W |
| Max Power per Port | 30W |
| Switching Capacity | 56 Gbps |
| Forwarding Rate | 41.66 Mpps |
| Security Features | ARP Inspection, IP Source Guard, DoS Protection, Port Security, DHCP Snooping |
| Network Management | Embedded Web UI, GWN.Cloud, GWN Manager |
| Protocol Support | IPv4, IPv6, IEEE 802.3af/at, VLAN, QoS |
| Mounting Options | Desktop, wall, or rack (mounting accessories included) |
