Description
R2W97A
R2W97A Specification | |
Radios | Dual radio for simultaneous dual-band operation 5 GHz 802.11ac 2×2 MIMO for up to 867 Mbps wireless data rate, with Multi User MIMO support (Wi-Fi 5) 2.4 GHz 802.11n 2×2 MIMO for up to 300 Mbps wireless data rate (Wi-Fi 4) |
Interfaces | Uplink Gigabit Ethernet port, with PoE-in support (802.3af) DC power connector (12V) Bluetooth Low Energy (BLE) radio LED status indicators (2) Reset/LED control button Kensington security slot |
Antennas | Integrated down-tilt omni-directional antennas with maximum individual antenna gain of 3.3dBi in 2.4GHz and 5.8dBi in 5GHz |
Dimension | 152mm x 152mm x 34mm, excluding mount accessories |
Power | Power over Ethernet (POE): 802.3af (class 3) Max power consumption (worst-case): 10.1W (PoE), 8.8W (DC) DC power (12V) Note: Power sources are sold separately |
Mounting | The access point ships with a (black) mount clip to attach to suspended ceiling rails, and a (white) mount clip to attach to solid surfaces (wall/ceiling) |
Environmental & reliability | Operating temperature: 0° C to +40° C (+32° F to +104° F) MTBF: 795khrs (91yrs) at +25° C |
Industry certifications | UL 2043 plenum rating EN 60601-1-1 and EN 60601-1-2 (for deployment in medical environments) Wi-Fi Alliance certified (WFA) 802.11ac with Wave 2 (Wi-Fi 5), WPA2, WPA3 |
Management options | Instant On mobile application (Android & iOS) Cloud Portal: Portal.ArubaInstantOn.com |
