The Netsys NS-501GL12U6045 is a professional-grade, wall-mounted server rack designed for high-efficiency networking in tight spaces. With a 12U capacity and a shallow 450mm depth, it is specifically engineered for “edge” networking—housing patch panels, switches, and shallow AV equipment where a full-sized floor cabinet isn’t feasible.
Technical Specifications
| Feature | Specification |
| Model | NS-501GL12U6045 |
| Form Factor | 12U Wall-Mount (Standard 19″) |
| Dimensions (WxDxH) | 600mm x 450mm x 635mm |
| Material | SPCC Cold Rolled Steel |
| Load Capacity | Up to 60kg (Static Load) |
| Front Door | Toughened glass with lockable swivel handle |
| Finish | Degreasing, Phosphoric, Powder Coated |
Key Features
-
Space-Saving Profile: The 450mm depth is the standout feature. It allows the rack to be installed in hallways, closets, or small retail offices without obstructing foot traffic, while still providing ample vertical space (12U) for a complete network stack.
-
Thermal Efficiency: The top and bottom panels feature vented slots for natural convection. Additionally, the top panel is pre-configured with a mounting hole for a 120mm cooling fan to ensure active heat dissipation for high-performance switches.
-
Secure & Transparent: The tempered glass front door provides a high-end look and allows for instant visual status checks of LED indicators without needing to unlock the cabinet.
-
Easy Maintenance: Features removable side panels with quick-release latches, allowing technicians to access the sides of equipment for wiring or hardware swaps without dismounting the entire rack.
-
Flexible Cable Entry: Multiple knock-out holes on the top and bottom covers provide clean cable routing, helping to maintain a professional and organized look.
Ideal Applications
-
SMB Networking: Housing a router, 24/48-port switch, and patch panel.
-
Smart Home/AV: Organizing home automation controllers, amplifiers, and media servers.
-
Security Systems: Securing an NVR (Network Video Recorder) and PoE injectors for CCTV setups.
Note: Because this is a 450mm deep model, it is not suitable for full-depth enterprise servers. Please verify that your equipment’s mounting depth is less than 350mm–400mm to allow for cable clearance at the rear.
