The Netsys NS-501GL9U6060 is a professional 9U wall-mount network cabinet designed to provide a compact and secure solution for small to medium-scale network distribution points. With its elegant glass door and a specialized 600 mm depth, this cabinet offers sufficient space to house active network devices while ensuring an organized and professional appearance within offices or hallways.
Key Features
-
Space-Saving Wall-Mount Design (9U): Ideal for facilities where floor space is unavailable. It can be mounted on walls to organize switches, patch panels, and surveillance recording units (NVRs) in an elevated and secure manner.
-
Full Visibility & Protection: Features a tempered glass front door that allows for a quick glance at equipment status and connections, while protecting them from tampering and dust and reducing operational noise.
-
Superior Operating Depth (600 mm): Unlike traditional shallow wall cabinets, the 600 mm depth of this model provides greater flexibility to accommodate slightly deeper devices and offers comfortable space for bending and organizing fiber optic and copper cables.
-
Efficient Ventilation System: The cabinet includes side and top ventilation slots, with pre-drilled holes for installing cooling fans to ensure air circulation and prevent sensitive electronics from overheating.
-
Easy Access & Installation: Constructed from high-quality SPCC cold-rolled steel, featuring removable side panels to facilitate the setup and maintenance process, and lockable front doors to ensure physical security.
-
Rugged Industrial Structure: Despite its compact size, it boasts high durability and excellent load-bearing capacity, ensuring the stability of heavier equipment such as small rack-mount UPS units.
Technical Specifications
| Feature | Specification |
| Height | 9U (Wall-Mount) |
| Dimensions (WxD) | 600 mm x 600 mm |
| Front Door | Tempered Glass with Security Lock |
| Side Panels | Removable and Lockable |
| Cooling | Dedicated slots for fan installation (Fans optional) |
| Cable Entry | Protected top and bottom entry points |
| Material | Premium SPCC Cold Rolled Steel |
| Mounting Type | Wall Mount or Desktop |
Best Use Case
The NS-501GL9U6060 is the ideal choice for small offices, bank branches, and smart homes. It is best suited as an Intermediate Distribution Frame (IDF) for connecting surveillance cameras or Wi-Fi Access Points (APs), providing a safe and organized location for equipment away from unauthorized hands while remaining easily accessible for maintenance.
