Product Definition:
The D-Link DGS-F108 is an unmanaged switch offering 8 RJ-45 Gigabit ports (up to 1000 Mbps), providing an affordable and reliable network expansion solution for small office or home setups.
Key Uses:
- Connect multiple devices such as PCs, printers, surveillance cameras, and access points.
- Ideal for online gaming and VoIP applications.
- Supports HD video streaming and IPTV using IGMP Snooping.
Usage Warnings:
- Not suitable for complex or managed network environments.
- Ensure proper power supply (12 VDC, 1 A) to avoid damage.
- Extremely high or low ambient temperatures may degrade performance or lifespan.
Technical Specifications Table:
| Specification | Details |
|---|---|
| Ports | 8 × RJ45 10/100/1000 Mbps |
| Transmission Rate | 10/100 Mbps half/full duplex, 100/1000 Mbps full duplex |
| Switching Bandwidth | 16 Gbps (non-blocking) |
| MAC Address Table | 4 K entries |
| Forwarding Rate (PPS) | Ethernet: 14,880 pps Fast Ethernet: 148,809 pps Gigabit: 1,488,000 pps |
| Standards | IEEE 802.3 / 802.3u / 802.3ab / 802.3x |
| LED Indicators | Power + per-port LINK/ACT |
| Power Supply | 100–240 VAC → 12 VDC, 1 A |
| Dimensions | 125 × 75 × 27 mm |
| Weight | 0.45 kg |
| Operating Conditions | Temperature: 0 °C–40 °C Humidity: 10%–90% non-condensing |
