The Netsys NS-401SM012 is a professional-grade 12-core OS2 Singlemode fiber optic cable, engineered for high-speed, long-distance data transmission. Featuring a precision 9/125µm core/cladding diameter, this carrier-class cable is the industry standard for backbone infrastructure, providing virtually unlimited bandwidth potential and minimal signal attenuation over several kilometers.
Technical Specifications:
| Feature | Details |
| Brand/Model | Netsys NS-401SM012 |
| Fiber Category | OS2 Singlemode (Low Water Peak) |
| Fiber Count | 12 Cores |
| Core/Cladding | 9/125µm |
| Transmission Distance | 10km to 40km+ (Transceiver dependent) |
| Data Rate Support | 1G, 10G, 40G, 100G, 400G Ethernet |
| Attenuation | $\leq 0.35$ dB/km @ 1310nm; $\leq 0.22$ dB/km @ 1550nm |
| Standard Jacket Color | Yellow (Standard for OS2) |
Key Product Features
-
High-Performance OS2 Glass: Optimized with “Low Water Peak” characteristics to ensure peak performance across the entire 1260nm to 1625nm wavelength spectrum.
-
12-Core Standard Configuration: Perfectly sized for standard 12-port fiber patch panels and MPO/MTP termination, offering a clean and scalable solution for network closets.
-
Future-Proof Bandwidth: Unlike multimode fibers, OS2 Singlemode has no modal dispersion limits, making it fully compatible with next-generation 400G and 800G hardware.
-
TIA/EIA Color-Coded Cores: All 12 fibers are individually color-coded for rapid identification, reducing installation time and errors during fusion splicing.
-
Robust Environmental Shielding: Features a durable outer jacket and internal strength members (typically aramid yarn) to protect the glass cores during high-tension pulls.
Primary Applications
-
Building-to-Building Links: Creating high-speed, interference-free connections across a corporate or university campus.
-
Enterprise Backbones: Serving as the primary vertical riser or horizontal link for large-scale networking environments.
-
ISP & Telecom Infrastructure: Ideal for Fiber-to-the-Building (FTTB) and distribution point aggregation.
-
Security & Surveillance: Long-haul transmission for high-resolution IP camera networks over distances that exceed multimode limits.
