The NS-402OM2024 is a high-density, 24-core OM2 Multimode fiber optic cable designed for reliable, high-bandwidth data transmission in local area networks (LANs). Featuring a 50/125µm core/cladding diameter, this cable is a versatile solution for enterprise-level backbones where Gigabit Ethernet (1GbE) is the primary requirement over extended distances.
Technical Specifications: NS-402OM2024
| Feature | Details |
| Model Number | NS-402OM2024 |
| Fiber Category | OM2 Multimode |
| Fiber Count | 24 Cores |
| Core/Cladding Diameter | 50/125µm |
| Gigabit (1GbE) Support | Up to 600 Meters (@ 850nm) |
| 10G Ethernet Support | Up to 82 Meters (@ 850nm) |
| Overfilled Launch Bandwidth | 500 MHz·km @ 850nm / 500 MHz·km @ 1300nm |
| Standard Jacket Color | Orange |
Key Performance Features
-
High-Density 24-Core Design: Provides massive capacity in a single cable pull, making it ideal for large-scale backbone installations and reducing the need for multiple cable runs.
-
Cost-Effective Networking: Offers superior performance and longer distance support for Gigabit Ethernet compared to legacy OM1 (62.5/125) fiber.
-
Standard 50/125µm Geometry: Compatible with most modern LED-based and some laser-based optical equipment, ensuring broad hardware interoperability.
-
Organized Core Management: The 24 fibers are color-coded according to TIA/EIA-598 standards, simplifying splicing, termination, and troubleshooting.
Ideal Use Cases
-
Campus Backbones: Connecting multiple buildings or wings where distances exceed the limits of copper cabling.
-
Enterprise LANs: Serving as the main vertical riser or horizontal backbone for large office complexes.
-
Legacy System Support: An excellent choice for maintaining or expanding existing OM2 infrastructures without the higher cost of OM3/OM4.
-
Security & Surveillance: High-capacity link for IP camera networks and integrated building management systems.
