The NS-AD-SC-APC-SX is a specialized variant of the SC adapter line, specifically engineered for networks that require the highest level of signal purity. By utilizing Angle Physical Contact (APC) technology, this adapter is designed to virtually eliminate back reflection, making it indispensable for high-power optical systems and video transmission.
Netsys NS-AD-SC-APC-SX
The Netsys NS-AD-SC-APC-SX is a high-precision SC-to-SC Simplex Fiber Optic Adapter designed for Single-Mode (SM) applications utilizing APC polishing. Featuring the industry-standard green housing, this adapter ensures a secure and precise alignment for angled fiber end-faces, providing the ultra-low return loss necessary for sensitive telecommunications and CATV equipment.
Key Features
-
APC (Angled Physical Contact) Optimized: Specifically designed to house green-coded APC connectors. The internal alignment is precision-tuned to accommodate the 8-degree angle of APC ferrules, minimizing back reflection (ORL).
-
Single-Mode Efficiency: Tailored for $9/125\mu m$ Single-Mode fiber networks, ensuring peak performance over long-distance links.
-
High-Grade Zirconia Sleeve: Features a premium zirconia ceramic split sleeve that maintains strict core-to-core alignment, ensuring consistent low insertion loss over hundreds of matings.
-
Simplex Space-Saving Design: A compact, single-port (Simplex) configuration ideal for precise point-to-point patching and individual subscriber terminations.
-
Rugged Construction: Built with a durable, flame-retardant plastic housing and integrated metal mounting clips for a secure “snap-in” fit in standard SC cutouts.
Technical Specifications
| Feature | Specification |
| Model | NS-AD-SC-APC-SX |
| Adapter Type | SC to SC (Female to Female) |
| Fiber Mode | Single-Mode (SM) |
| Configuration | Simplex (SX) |
| Polish Type | APC (Angled Physical Contact) |
| Sleeve Material | Zirconia Ceramic |
| Insertion Loss | $\le 0.2$ dB |
| Color | Green (Industry Standard for APC) |
| Mounting | Flanged with integrated metal clips |
Best Use Case
The NS-AD-SC-APC-SX is the go-to solution for GPON/FTTH networks, CATV (Cable TV) systems, and high-speed DWDM applications. Because APC connectors minimize the noise caused by reflected light, this adapter is critical for analog video signals and high-power satellite distributions where signal integrity is paramount.
