Netsys NS-AD-SCSC-UPC-SM-DX
The Netsys NS-AD-SCSC-UPC-SM-DX is a high-performance Duplex SC-to-SC Fiber Optic Adapter designed to join two pairs of SC fiber connectors. By doubling the density in a single housing, this adapter is engineered for high-density Single-Mode (SM) environments, providing seamless connectivity with superior signal stability and Ultra Physical Contact (UPC) compatibility.
Key Features
-
Duplex (DX) Configuration: Features a dual-channel SC-to-SC interface, allowing two separate fiber connections to be housed in one unit—perfect for saving space in high-density panels.
-
Single-Mode Precision: Optimized for $9/125\mu m$ Single-Mode fiber strands, ensuring maximum efficiency for long-haul telecommunications.
-
Dual Zirconia Ceramic Sleeves: Equipped with two independent high-quality zirconia alignment sleeves to ensure precise core alignment for both channels, reducing signal attenuation.
-
Low Back Reflection: Designed for UPC (Ultra Physical Contact) polished connectors, maintaining a high return loss and protecting sensitive optical transmitters.
-
Snap-In Installation: The durable blue plastic housing includes integrated stainless steel mounting clips for easy, tool-free installation into standard duplex cutouts.
Technical Specifications
| Feature | Specification |
| Model | NS-AD-SCSC-UPC-SM-DX |
| Adapter Type | SC to SC (Female to Female) |
| Fiber Mode | Single-Mode (SM) |
| Configuration | Duplex (DX) |
| Sleeve Material | Zirconia Ceramic |
| Insertion Loss | $\le 0.2$ dB |
| Color | Blue (Industry Standard for SM UPC) |
| Mounting | Flanged with integrated metal clips |
Best Use Case
The NS-AD-SCSC-UPC-SM-DX is ideal for high-density Fiber Patch Panels and Data Center enclosures where doubling the port count is necessary without increasing the physical footprint. It is the standard choice for enterprise networking, backbone infrastructure, and duplex FTTH (Fiber to the Home) applications requiring reliable, high-speed bi-directional communication.
