The Netsys NS-LCUPC-LCUPC-DX-SM-5M is a high-performance Single-mode (OS2) Duplex Fiber Optic Patch Cord designed for high-speed, long-distance data transmission in enterprise and telecommunications networks. Measuring 5 meters (approx. 16.4 feet), this cable provides the necessary reach for connecting networking hardware across server racks or within a structured cabling environment.
Key Features
-
OS2 Single-mode Fiber: Features a precision 9/125µm core optimized for 1310nm and 1550nm wavelengths, offering virtually unlimited bandwidth and much lower signal attenuation than multimode fiber.
-
LC-to-LC Duplex Connectors: Equipped with Small Form Factor (SFF) LC connectors to maximize port density on high-end switches. The duplex design supports simultaneous bi-directional data flow (TX/RX).
-
Ultra Physical Contact (UPC) Polish: Both blue LC connectors feature a UPC finish, ensuring an exceptionally low insertion loss (≤ 0.3dB) and a high return loss (≥ 50dB) for superior signal stability.
-
Versatile 5.0m Length: The 5-meter reach is ideal for routing through vertical cable managers or overhead trays, providing flexibility for connecting non-adjacent equipment while maintaining a tidy installation.
-
Industry-Standard Yellow Jacket: Wrapped in a yellow jacket for instant identification as Single-mode fiber, helping technicians avoid cross-connection with multimode infrastructure.
Technical Specifications
| Feature | Specification |
| Fiber Type | Single-mode OS2 (9/125µm) |
| Connectors | LC/UPC to LC/UPC (Duplex) |
| Length | 5.0 Meters (approx. 16.4 feet) |
| Jacket Color | Yellow |
| Operating Wavelength | 1310nm / 1550nm |
| Insertion Loss | ≤ 0.3 dB |
| Return Loss | ≥ 50 dB |
Best Use Case
The NS-LCUPC-LCUPC-DX-SM-5M is the preferred choice for critical network uplinks. it is commonly used to connect SFP+ or QSFP LR (Long Reach) transceivers to fiber distribution panels, facilitating stable 10G/40G/100G connections across a facility.
