Product Definition
The TP-Link TL-SG1008D is an unmanaged desktop switch featuring eight RJ-45 Gigabit ports. It provides an effortless way to upgrade legacy networks to 1 Gbps. Designed for plug-and-play use—no configuration required.
Key Use Cases
- Expanding home or small office networks with additional Gigabit ports.
- Fast transfer of large files—graphics, video, or media—between connected devices.
- Ideal for creative production, workgroups, or environments requiring high-speed networking.
Usage Warnings
- Only use the TP-Link supplied power adapter to prevent damage or compatibility issues.
- Ensure proper ventilation to avoid overheating.
- Avoid operation in high-humidity or harsh environmental conditions.
Technical Specifications Table
| Specification | Details |
|---|---|
| Ports | 8 × 10/100/1000 Mbps RJ-45 ports, Auto-Negotiation, Auto-MDI/MDIX |
| Energy-Saving Tech | Green Ethernet: powers down idle ports and adjusts power usage based on cable length (up to 80% savings) |
| Flow Control | IEEE 802.3x (Full-Duplex) and Backpressure (Half-Duplex) |
| Switching Architecture | Non-blocking, full wire-speed forwarding |
| Jumbo Frame Support | Up to 15 KB (some versions ~9 KB) |
| Switching Capacity | 16 Gbps |
| MAC Address Table | 4k–8k entries |
| Dimensions | Approx. 180 × 90 × 25 mm |
| Power | External adapter 9 V ⎓ 0.6 A |
